Input |
MC4 Solar Panel Cable (Input): Rated: 12-60 V, max current: 20 A, max power: 1200 W*
XT90 Car/Solar Charging Port (Input): Rated: 12-45 V, max current: 43 A, max power: 600 W*
SDC Port (Output): 40-58.4 V
* Measured at an ambient temperature of 25° C when being recharged at 60 V and 20 A.
** Measured at an ambient temperature of 25° C when connected to a 12V car system and being recharged at 14 V and 43 A. |
Output (Power Supply with Solar Power) |
SDC Port (Input): 40-58.4 V
XT60 DC Output/Micro-Inverter Port: 40-58.4 V, max current: 15 A |
Output (Power Supply with Car Power) |
SDC Port (Input): 40-58.4 V
XT90 Car/Solar Charging Port (Output): 12V Car System: 11-14.4 V, 600W max power* 24V Car System: 22-28.8 V, 600W max power*
* At ambient temperatures between 0° to 45° C, it can continuously recharge DJI Power 1000 at 600 W via the car's alternator. |
Charging Temperature |
0° to 45° C |
Power Supply Temperature |
-10° to 45° C |
