Zenmuse V1

Item Code: ZENMUSEV1

Reach Loud and Clear

Key Features:

• Voice + TTS Audio Broadcast
• 500m Effective Audio Range
• Directional Voice Broadcasting

AUD $1,499.00

Clear Communication

Name: Zenmuse V1
Brand: DJI
Price: 1499 AUD
Availability: InStock

Broadcast audio effectively with Zenmuse V1, a powerful loudspeaker payload designed for Matrice 300 series. With multiple broadcast modes, Zenmuse V1 is effective at a variety of ranges and can be deployed in emergency response scenarios, be used to aid agricultural operations and more.

Record & Broadcast

Record audio via DJI RC Plus’ directional built-in microphone, save it and share it in seconds.

Ideal for emergency scenarios, Record & Broadcast mode empowers you to rapidly record and share critical messaging in a flash.

Paired with environmental noise cancellation technology, messaging remains clear, even when recorded in noisy environments.

Text to Speech

Deploy easy-to-use Text to Speech and have Zenmuse V1 intelligently broadcast text that you write. With variable tone and speech rate, in addition to loop playback, messages can be delivered to the audience clearly and efficiently.

Audio File Playback

V1 supports playback of MP3, ACC and WAV audio files through DJI Pilot 2, allowing users to quickly disseminate pre-recorded information.

Superior Sound

Loud & Proud

Zenmuse V1 delivers a maximum broadcast range of 500m for effective communication from a distance. And, with sound pressure level up to 127 dB at 1 metre, messages will reach their audience, regardless of environmental noise.

Synchronised Sound

Zenmuse V1 syncs with other gimbals for coordinated tilt angles, directing sound accurately in the intended direction.

Users can precisely control and target the direction of audio transmission via gimbal synchronisation.

Shortcut Operation

Optimise operational efficiency with support for customisable controller shortcuts.

Capture audio recordings with just one tap and broadcast them with just one more.

Mobile SDK

Unlock custom functionality with support for Mobile SDK and pair Zenmuse V1 with third-party mobile apps.

Designed for users with specialised needs.

Mount Anywhere, Operate Any Time

Zenmuse V1 can be mounted to Matrice 300 series in any orientation to suit your setup needs. Plus, with an IP54 rating suitable for temperatures ranging from -20° to 40° C, you can operate virtually anywhere, at any time with strong environmental adaptability.

Ample Applications

Search & Rescue

Law Enforcement

Emergency Response

Wildlife Deterrence

Livestock Management

Payload Protection

Hearing Protection

On the ground? Zenmuse V1 automatically sends pop-up reminders when volume exceeds 40%, to ensure safe volume levels when not in flight.

Internal Protection

The payload sports multiple protection mechanisms for temperature, overcurrent and power to ensure reliable performance, mission after mission.

Talk to a DJI Enterprise Expert

Learn More with D1 Blog

Visit our YouTube Channel

* All data on this page was collected using a production model in a controlled environment. Actual results may vary depending on the environment, usage, and firmware version.

** All videos and photos on this page were taken in strict compliance with local laws and regulations. Demos are for reference only. Please observe local laws and regulations and ensure that the aircraft has obtained relevant certifications before flying.

**** To ensure that the equipment operates steadily and continuously, please perform regular maintenance.

Weight	690±10 g
Dimensions	134×119×140 mm (L×W×H)
Rated Power	30 W
Shell Temperature	<50° C (122° F, plastic shell) ^{Masured in a laboratory environment with the speaker installed on the aircraft at an ambient temperature of 25° C (77° F).}
Ingress Protection Rating	IP54 ^{Under controlled laboratory conditions, it can achieve an IP54 protection rating by IEC60529 standards. The IP rating is not permanently effective and may decrease due to product wear and tear.}

Operating Temperature	-20° to 50° C (-4° to 122° F)
Storage Temperature	-20° to 60° C (-4° to 140° F)

Stabilization System	Single-axis (tilt)
Angular Vibration Range	Hover: ±0.01° Flight: ±0.02°
Mounting	Detachable DJI SKYPORT
Mechanical Range	Tilt: -125° to +25° ^{Structural limit, not controllable range.}
Controllable Range	Tilt: -120° to +20°
Operation Mode	Follow / Free / Re-center

Impedance	4 Ω
Nominal Power	25 W
Effective Broadcast Distance	500 m ^{Measured in a laboratory environment at 25° (77° F) . Actual conditions may vary slightly due to software version, audio source, specific environment, and other factors. The final effect is subject to actual use..}
Max Sound Pressure Level	127 dB @1 m ^{Measured in a laboratory environment at 25° (77° F) . Actual conditions may vary slightly due to software version, audio source, specific environment, and other factors. The final effect is subject to actual use.}
Effective Bandwidth	800 Hz to 8 kHz

Record & Broadcast	Record & broadcast, local playback, and storage
Text-to-Speech	Text-to-speech and storage (supports English and Mandarin Chinese)
Audio File Playback	Supports importing local files in MP3, AAC, and WAV formats
Playback Control	Start / Stop recording / Loop playback / Volume adjustment
Remote Controller Button	Can set one button to press once to start recording, and press again to stop and play the recording.
Gimbal Synchronization	Supports synchronized control with other gimbal-equipped payloads

Directional Audio Recording	The remote controller supports directional audio pickup and environmental noise reduction
Payload Protection	Speaker temperature protection, overcurrent protection, and power protection to prevent damage.
